BALCONY LIVING ROOM
1BHK 2BHK
AREA 7.2 sqm AREA 7.2sqm
Slightly more area provided for efficient use of Balcony is designed with a foldable seat.
recreational space and ventilation

IMPORTANT
• Primary living spaces near the corridor.
• Secondary Living spaces with the toilet are provided.
• Balcony on the further side.
• Opening provided on one side of the dwelling for perfect ventilation and lighting throughout the day with respect to elderly.

UNITS
KITCHEN BALCONY TOILET BEDROOM LIVING
Combination of Integral part of the unit Ergonomically Private zone with Provision of
Kitchen & Dining for providing the essential designed for close proximity to the social
ease of access , max light, ventilation and the elderly for the toilet w.r.t elderly. recreational
utility and optimum exposure to green ease of access. Provision of an and unwinding
functions. spaces Emergency door. space in the
unit.
TYPE A TYPE C
Passage to the balcony Obstruction of light
is from kitchen. therefore openings go
Double door for toilet in vain
No ease of circulation.

TYPE B FINAL MODULE
Improper circulation Optimum lighting and
increases the strain ventilation and perfect
on elderly’ circulation for the
elderly user group.

TYPE A TYPE C
No proper ventilation No ease of access to
from any side. the toilets for elders
living in both rooms.

TYPE B
Haphazard circulation FINAL MODULE
and no connection to Good circulation and
the balconies optimum lighting for
the whole unit.
