HRRL TOWNSHIP AT BARMER, RAJASTHAN
Site Plan
LEGEND
1.Type A 12.Community Hall 23. Amphitheater 34.Play ground
2.Type B 13.Club House 24. Future Expansion 35.Parade ground
3.Type C 14.Auditorium 25.MRS block 36.Play ground with shops
4.Type D 15.Sports complex 26.Overheat tank 27.Sewage 37.Kabbadi Court
5.Type E 16. Township office treatment 38. Cricket field
6.Type F 17.Bus Stand 28.Garbage Room 39.Football ground
7.Dwelling units for CISF 18.Public Toilet 29.Barracks 40.Volly ball ground
8. CISF Staff Quarters 19.Taxi Stand 30.Canteen 41.Lawn Tennis
9.Anganwadi 20.Main Gate House. 31.Gymnasium 42.Badminton Court.
10.Shopping complex 21.Gate house. 32.Sanrakshika store 43.Swimming Pool
11.Guest House 22.Watch tower 33. Main Gate for CISF
