FORM DEVELOPMENT ACTIVITIES
STACKING OF MODULE
To form a multi storey building. Each
unit will get views from both the
sides.
NEGATIVE TRANSFORMATION
to create voids to form multiple
gathering and open spaces.
CONNECTING THE TWO
BLOCKS gives access and creates
multiple gathering spaces at the
junction of blocks.
Addition of CORES FOR
VERTICAL MOBILITY
(elevators and staircase).
STAGGERED PROJECTIONS
create active spaces for gathering
infront of the residential units.
TYPOLOGY 1 TYPOLOGY 2 TYPOLOGY 3 HIGH RISE
