SANITATION
          SANIT   A TION


         Ÿ A  crane  picks  up  the  waste  and  dumps  it  into  a   MOBILISATION OF RESOURCES:                               Specifications of the Plant
           combustion chamber.                                JWCTMPL is the waste collection and transportation firm
                                                                                                                                S. No.  Parameter                          Details
         Ÿ The waste is burned, generating heat.              which works under JMC, it provides waste collected from
                                                                                                                                Plant Capacity
         Ÿ The heat turns the water in the attached boiler into   households to the WTE plant. The tipping fee of C&T is
           steam.                                                                                                               1.     Power Generating Capacity           11.5 MW
                                                              Rs. 1470/ton.
         Ÿ The  high-pressure  steam  forces  a  turbine  to  spin,                                                             2.     Waste processing Capacity           600 TPD
           producing electricity.                                                                                               Technical Detail
                                                                                                                                3.     Land Area of main plant             10 Acres
                                                                                                                                4.     Land Area of Scientific land fill (Acres)  NA

                                                                                                                                5.     Technology Used for segregation of waste  NA but Trommel used for old SLF waste segregation, since it is a mass
                                                                                                                                                                           burning facility.
                                                                                                                                6.     Technology used for energy generation  Controlled combustion system
                                                                                                                                7.     Specifications of Boiler             Hitachi make single drum water tube boiler 56.4tph, 46 bar, 408°c, with
                                                                                                                                                                           forward moving reciprocating grate.
                                                                                                                                8.     Specifications of Turbine            Siemens make 1 x 11.5MW (12.3MW VWO), Model SST300 – C1S/
                                                                                                                                                                           V36UB Bleeding cum Condensing Steam Turbine.
                                                                                                                                9.     Detail of BTG suppliers             TDPS make generator, frame TC 150, 15437.5KVA, 12.35MW, 11000
                                                                                                                                                                           Volts, 810 amperes,
                                                                                                                                10.    Detail of EPC contractor            Consortium of Hitachi and Isgec John Thomson (IJT).
         Technology                                                                                                             11.    Cooling Technology                  Air Cooled Condenser, C Doctor make
                                                                                                                                12.    Power Evacuation Voltage Level      132 KV
                                                                                                                                13.    Plant Maintenance Schedule          Once after 8000 hours of operation.
                                                                                                                                       (Shutdown instances and reason thereof)



                                                                                                                               Impacts- Post Implementation                          Ÿ Reduction  of  approximately  37,000  tons  of  carbon
                                                                                                                                                                                        emission in Jabalpur.
                                                                                                                               Ÿ After running successfully since last 3 years, there is
                                                                                                                                  no single small heap of waste in Jabalpur and the city is   Ÿ 4.4  hectares  of  land  can  be  saved  by  processing
                                                                                                                                  free from MSW                                         2,19,000 tons of solid waste per year.

        Emission regulations and Jabalpur emission Levels                                                                                                                            Ÿ This technology saves in operating costs.
                                                                                                                                  •  Improved physical health of citizens
                       3
             In mg/Nm                European              India: Municipal Solid        Jabalpur Plant                           •  Recovery and Recycling                          Ÿ Preheating  of  combustion  air  to  high  temperature
                               Directive 2000/76/EC              Wastes-2016             Emission Levels                                                                                allows combustion without using any auxiliary fossil
                                                                                                                                  •  Reduction of  greenhouse gases
                                                                                                                                                                                        fuel.
                Dust                       10                         50                        09                                •  Generation of clean energy
                                                                                                                                                                                     Ÿ Improved efficiency due to preheating with turbine
                CO                         50                        100                        40                                •  Reduction of carbon emissions                      bleed steam.

                NOx                       200                        400                        20                             RESULT ACHIEVED:                                      Ÿ Based on the heat value of the waste, a by-pass system
                                                                                                                                                                                        is provided for air pre-heaters to control primary air
                                                                                                                               Ÿ Essel Infraprojects is the first company to introduce
                HCl                        30                         50                        24                                                                                      temperature.
                                                                                                                                  Hitachi Zosen's thermal waste processing solution in
                SO                         50                        200                        28                                India.                                             Recommendations – Action Plan for Improvement
                   2
                                                                                                                               Ÿ 11.5 MW energy generated; equivalent to providing   Recommendations at Central, state and municipal levels
              All emissions values corrected to 11% Oxygen on a dry basis as per MSW Rules 2016.
                                                                                                                                  electricity to 18,000 households.                  may be as below:


                                                          { 94 }
                                                          { 94 }
                                                          { 94 }                                                                                                                 { 95 }
